| Part No |
90NB14U1-M004X0 |
| EAN |
|
| Operating System |
No preinstalled OS |
| Color & Material |
LCD Cover: Jade Black, Aluminum
Top Case: Jade Black, Aluminum |
| Military Grade |
US MIL-STD 810H military-grade standard |
| Backlit |
OLED(120HZ)-Narrow border |
| Panel |
14.0 OLED WQXGA+(WQ+) 2880X1800 16:10 Bend+400nits(HDR) Glare DCI-P3:100% |
| Oled |
OLED |
| Touch |
non-Touch |
| Processor |
AMD KRACKAN-8C/BGA |
| Integrated GPU |
AMD Radeon™ Graphics |
| Expansion Slot (includes used) |
1x M.2 2280 PCIe 4.0x4 |
| Total System Memory |
16GB |
| On board Memory |
LPDDR5X 16GB ( 16GB LPDDR5X on board ) |
| Storage Installed |
1TB PCIE G4 SSD |
| Storage Total |
1TB PCIE G4 SSD |
| Camera |
Front: FHD camera with IR function to support Windows Hello
Rear: -
With privacy shutter
World-Facing: - |
| Wireless |
Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.) |
| Screenpad |
|
| FingerPrint |
WO/FINGERPRINT |
| I/O Ports |
1x USB 3.2 Gen 1 Type-A (data speed up to 5Gbps)
1x USB 3.2 Gen 2 Type-C with support for display / power delivery (data speed up to 10Gbps)
1x USB 4.0 Gen 3 Type-C with support for display / power delivery (data speed up to 40Gbps)
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack |
| Audio |
Smart Amp Technology
Built-in speaker
Built-in array microphone |
| AC Adapter |
75WHrs, 4S1P, 4-cell Li-ion
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100-240V AC 50/60GHz universal |
| Battery |
75WHrs, 4S1P, 4-cell Li-ion |
| Keyboard type |
Backlit Chiclet Keyboard |
| Weight & Dimensions |
1.20 kg (2.65 lbs)
31.24 x 22.01 x 1.49 ~ 1.49 cm (12.30" x 8.67" x 0.59" ~ 0.59") |
| Security |
BIOS Booting User Password Protection
BIOS setup user password
Microsoft Pluton security processor
Trusted Platform Module (Firmware TPM)
IR webcam with Windows Hello support
McAfee® |
| Included in the Box |
Sleeve |
