| CPU |
Intel® Celeron® J6412 4-core/4-thread processor, burst up to 2.6 GHz |
| CPU Architecture |
64-bit x86 |
| Graphic Processors |
Intel® UHD Graphics |
| Floating Point Unit |
Yes |
| Encryption Engine |
(AES-NI) |
| Hardware-accelerated Transcoding |
Yes |
| System Memory |
8 GB on board (non-expandable) |
| Maximum Memory |
8GB |
| Flash Memory |
4GB (Dual boot OS protection) |
| Drive Bay |
2 x 3.5-inch SATA 6Gb/s
The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/
|
| Drive Compatibility |
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
Yes |
| M.2 Slot |
2 x M.2 2280 PCIe Gen 3 x2 |
| SSD Cache Acceleration Support |
Yes |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
| Wake on LAN (WOL) |
Yes |
| Jumbo Frame |
Yes |
| USB 2.0 port |
2 |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-A |
| HDMI Output |
2 x HDMI 1.4b ( up to 3840 x 2160 @ 30Hz ) |
| Form Factor |
Tower |
| LED Indicators |
Power/Status, LAN, USB, HDD1-2 |
| Buttons |
Power, Reset, USB Auto Copy |
| Dimensions (HxWxD) |
168,5 × 102 × 225 mm |
| Weight (Net) |
1.28 kg |
| Weight (Gross) |
2.32 kg |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
60W/65W adapter, 100-240V |
| Power Consumption: HDD Sleep Mode |
10.56 W |
| Power Consumption: Operating Mode, Typical |
18.09 W |
| Fan |
1 x 70mm, 12VDC |
| System Warning |
Buzzer |
| Kensington Security Slot |
Yes |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
1500 |
