| CPU |
ARM 4-core Cortex-A55 2.0GHz processor |
| CPU Architecture |
64-bit ARM |
| Graphic Processors |
Mali-G52 |
| Floating Point Unit |
Yes |
| Encryption Engine |
Yes |
| Hardware-accelerated Transcoding |
Yes |
| Neural Processing Unit (NPU) |
Yes |
| System Memory |
4 GB on board (non-expandable)
Note: Reserves some RAM for use as shared graphics memory.
|
| Maximum Memory |
4 GB on board (non-expandable) |
| Flash Memory |
4 GB (Dual boot OS protection) |
| Drive Bay |
2x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
Yes |
| Gigabit Ethernet Port (RJ45) |
1 |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
1 (2.5G/1G/100M) |
| Wake on LAN (WOL) |
Yes |
| Jumbo Frame |
Yes |
| USB 2.0 port |
2 |
| USB 3.2 Gen 1 port |
1 |
| Form Factor |
Tower |
| LED Indicators |
System Status, LAN, USB, HDD1~2 |
| Buttons |
Power, Reset, USB Copy |
| Dimensions (HxWxD) |
165 × 102 × 220,6 mm
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
|
| Weight (Net) |
1.45 kg |
| Weight (Gross) |
2.41 kg |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
Minimum 48W adapter (12VDC), 100-240VAC |
| Power Consumption: Disk Standby Mode |
4.973 |
| Power Consumption: Operating Mode, Typical |
13.907 W
Tested with drives fully populated.
|
| Fan |
1 x 70mm, 12VDC |
| System Warning |
Buzzer |
| Kensington Security Slot |
Yes |
| Standard Warranty |
2 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
200 |
